C7
Features:
v Composite design for various applications.
v Support holder for Embedded, Antenna, Camera & Lens.
v Negative Pressure design to avoid the oil and dust pollution.
v Rotation Angle design to avoid the horizontal problem.
Applications:
v Speed enforcement
v Automatic number plate recognition
v Traffic integrated device
v Rail container scanning
v Red light violation
v Weigh in motion
Item Number | C7 | C7_20 | C7_30 | C7_D |
Product’s Name | Integrated Traffic Device | |||
Wavelength | NIR 850 nm | |||
Illumination Source | Latest High Power LED Technology | |||
Distance | 15 to 30m | 15 to 30m | 15 to 30m | 15 to 30m |
Trigger Modes | Trigger Mode (Flashes upon input pulse) | |||
Min. Repeat Time | 30us | |||
Max. Pulse Width | Full Strobe 0.1-1.6ms/ Strobe+PWM 0.1-6ms | |||
Trigger input | DC3.3V to 24V opto-isolated | |||
Control/ Communication | RS485 | |||
Beam Angle | 10 | 20 | 30 | H40xV15 |
Operating Temperature (°C) | -20~+60 degree | |||
Power Requirement | DC 24 to 48V @2A | |||
Weather Proof | IP66 | |||
Dimension | (L)245x (W)306 x (H)232 mm | |||
Net Weight | 5 Kgs | |||
Gross Weight | 6.5 Kgs | |||
