LV12_40

LV12-T_40

LV12-W_40

Product’s Name

Ultra High Power Illuminator

Wavelength (nm)

NIR 850 nm

Lane Coverage

-

Illumination Source (LEDs.)

Latest High Power Technology

Light Drive Power- Pulsed (watt)

-

IR Effective Range (meter)

50M

75M

100M

Luminous

-

Color Temperature

-

Trigger Modes

1.Alarm input (Sync with camera ICR function)

2.Alarm output (Sync with camera ICR function)

MAX. Trigger Frequency (kHz)

-

MAX. Pulse Width (ms.)

-

Trigger Input- opto-isolated (volt)

-

Beam Angle

40

40~90

40~150

Control Communication

RS485 interface

Operating Temperature (°C)

-40~+70 degree

Weather Proof

IP66

Power Consumption (Watt)

15W

30W

45W

Power Requirement (Volt)

DC 12V

Dimension (L x W x H mm)

(L)110 x(W)96 x(H)172 mm

(L)222 x(W)151 x(H)146 mm

(L)334 x(W)185 x(H)146 mm

Net Weight (kg)

0.6 kgs

1.1 kgs

2.1 kgs

Gross Weight (kg)

1.4 kgs

1.6 kgs

2.8 kgs
