LV6-T_Series
v Ideal for surveillance applications.
v Ultra high power- Low running cost.
v IP66 enclosure for outdoor installation.
v NIR 850nm wavelength.
v Compact LED Light source.
LV6-T | LV7-T | LV8-T | |
Product’s Name | eco High Power IR Illuminator | ||
Wavelength (nm) | NIR 850 nm | ||
Lane Coverage | - | ||
Illumination Source (LEDs.) | Latest High Power Technology | ||
Light Drive Power- Pulsed (watt) | - | ||
IR Effective Range (meter) | 100M | 40M | 30M |
Luminous | - | ||
Color Temperature | - | ||
Trigger Modes | 1.Alarm input (Sync with camera ICR function) 2.Alarm output (Sync with camera ICR function) | ||
MAX. Trigger Frequency (kHz) | - | ||
MAX. Pulse Width (ms.) | - | ||
Trigger Input- opto-isolated (volt) | - | ||
Beam Angle | 10~30 | 30~90 | 50~130 |
Control Communication | RS485 interface | ||
Operating Temperature (°C) | -40~+70 degree | ||
Weather Proof | IP66 | ||
Power Consumption (Watt) | 16W | ||
Power Requirement (Volt) | DC 12V | ||
Dimension (L x W x H mm) | (L) 185 x (W) 165 x (H) 115 mm | ||
Net Weight (kg) | 0.96 kgs | ||
Gross Weight (kg) | 1.4 kgs | ||
